The Pressure Relief: Aero-Louvred Wheel Arches // Blueprint R01
Engineering Note: In high-speed racing, the space inside a wheel well is a zone of aerodynamic conflict. This technical blueprint deconstructs the Integrated Fender Louvres, a critical solution for managing wheel-arch pressure. As the tire rotates at high velocity, it acts as a centrifugal pump, creating a high-pressure pocket that generates unwanted front-end lift.
Following the aerodynamic principles in Joseph Katz’s Race Car Aerodynamics, this piece visualizes the extraction of air through angled slats to equalize pressure. This process not only stabilizes the front axle but also cleans the airflow along the side of the chassis. It is a masterclass in passive pressure management, essential for the engineer who understands that speed is as much about what you extract as what you intake.
